Non-dewetting PTFE membrane
The non dewetting PTFE membrane provided by MS is made by modifying the e-PTFE membrane with a special coating. Through the unique modification technology of MS, hydrophilic functional groups with strong acid, alkali, and oxidation resistance are formed on the surface of PTFE membrane. Therefore, the surface energy of the modified PTFE membrane is improved, and compared to PTFE membrane, it can maintain a hydrophilic state for a long time in aqueous solution after alcohol infiltration. Strong acid filtration is widely used in the semiconductor industry.
Full Description
Online Ordering
暫無(wú)選擇項(xiàng)
Please Select a Item
Applied filters:
| Specs | Product | Parameters | Availability | Price |
|---|
Related Documents
 |
| Non-dewetting PTFE Membrane Datasheet |
Features
- Relatively high membrane surface energy（<30dyn）
- Wide temperature Range（-40°C - 260°C）
- Thickness（10-50μm）
- Resistant to strong acids, strong bases, and strong oxidants（eg.HNO3，H2SO4）
- Higher resistance to air pressure
Applications
- Strong acid and strong alkali filtration
- Solvent filtration in the semiconductor industry
Technical Parameters
|
Membrane Material |
PTFE |
|
Wetting Performance |
hydrophobic |
|
Support |
N(none) |
|
Width |
270mm/290mm(customizable) |
|
Thickness |
10-30um |
|
Chemical Performance |
Excellent |
|
Operation pH |
0-14 |
|
Operation Temperature |
-80℃-260℃ |
|
Pore Size |
0.05um，0.1um，0.22um，0.45um |
|
Membrane Testing Reports Available |
Bubble Point and Flow Test Report |
